Introduction to Low-pressure pneumatic ash conveying material sealing pump, introduction to Material seal pump function advantages and characteristics

Low-pressure pneumatic ash conveying material sealing pumpIt is a new type of pneumatic conveying equipment for powder, which belongs to the category of low-pressure dilute phase conveying, and mainly uses the ejector effect of high-speed airflow to convey powder materials.，Mainly used forRaw material transportation,System supporting use,Long-distance or complex terrain material transportation,Conveying of powdery materials andWaste disposal，it is mainly composed of Supporting and connecting parts, injector, sealing device, Nozzle adjusting device and Feed port and discharge port，This productThe overall structural design is simple, diverse and beautiful.，is a kind of high quality and low price Low-pressure pneumatic ash conveying material sealing pump，at the start of the operation,Using the action of air jet, the air drives the ash particles to send the ash to ash storage. The energy when the Low-pressure pneumatic ash conveying material sealing pump works comes from two parts: one part is the kinetic energy of the fan, and the other part is the potential energy of the material column. When the material column is high, the potential energy is high and the pressure is high, the conveying capacity is correspondingly large, and vice versa.。

1、Brief introduction of Low-pressure pneumatic ash conveying material sealing pump

Low-pressure pneumatic ash conveying material sealing pumpIt is a kind of powder pneumatic conveying equipment.。

Low-pressure pneumatic ash conveying material sealing pump

2、Structural advantages of Low-pressure pneumatic ash conveying material sealing pump

The Low-pressure pneumatic ash conveying material sealing pump has the following structure

1. Supporting and connecting parts

The supporting and connecting parts are used to support and connect various parts of the Low-pressure pneumatic ash conveying material sealing pump to ensure the stability and integrity of the pump body. The design and manufacture of these components need to consider factors such as strength, stiffness and stability.

2. Feed port and discharge port

The inlet is used to add powder materials into the Low-pressure pneumatic ash conveying material sealing pump, and the outlet is responsible for discharging the transported powder materials. The design of inlet and outlet needs to consider the fluidity, sealing and easy cleaning of powder.

3. Cylindrical pump body

The cylindrical pump body is the main part of the Low-pressure pneumatic ash conveying material sealing pump, which contains the nozzle and powder materials, and provides the necessary space for air flow and powder to be mixed and transported. The material and structure design of the pump body need to consider the factors such as wear resistance, corrosion resistance and sealing.

4. sealing device

The sealing device is an important part in the Low-pressure pneumatic ash conveying material sealing pump, which is used to ensure the tightness inside the pump body and prevent the leakage of airflow and powder. The design and manufacture of sealing device need to consider the factors such as wear resistance, corrosion resistance and sealing performance.

5. Supporting and connecting parts

The supporting and connecting parts are used to support and connect various parts of the Low-pressure pneumatic ash conveying material sealing pump to ensure the stability and integrity of the pump body. The design and manufacture of these components need to consider factors such as strength, stiffness and stability.

Low-pressure pneumatic ash conveying material sealing pump

3、Low-pressure pneumatic ash conveying material sealing pump performance advantage

The advantages of Low-pressure pneumatic ash conveying material sealing pump are as follows:

1. Simple structure and convenient operation

The Low-pressure pneumatic ash conveying material sealing pump has simple structure, convenient operation and small maintenance.

2. energy saving and environmental protection

The fully sealed design also reduces dust emission and is beneficial to environmental protection.

3. Continuous conveying

Powder can be continuously conveyed, and the conveying efficiency is improved. The equipment has the function of automatically adjusting the output, which can adjust the conveying capacity according to the actual demand and achieve good ash conveying effect.

4. regulate automatically

It can automatically adjust the output to achieve good ash conveying effect.

5. Low pressure transportation, little wear and tear.

The pressure of ash conveying medium is low, the valve of equipment pipeline is not easy to wear and has long service life.

Low-pressure pneumatic ash conveying material sealing pump

4、Low-pressure pneumatic ash conveying material sealing pump video

On-site aerial photography of Low-pressure pneumatic ash conveying material sealing pump。

Low-pressure pneumatic ash conveying material sealing pump

As you can see from the live video.，hyde the main features are Long service life, Pollution-free transportation, Small maintenance, Reliable operation and easy to operate。

5、Low-pressure pneumatic ash conveying material sealing pump use

The purpose of Low-pressure pneumatic ash conveying material sealing pump is introduced as follows:

1. Conveying of powdery materials

The Low-pressure pneumatic ash conveying material sealing pump is mainly used for conveying all kinds of dry and loose powder materials. These materials include but are not limited to fly ash, alumina powder, limestone powder, cement powder, dry kiln ash, etc. Through the efficient transportation of the Low-pressure pneumatic ash conveying material sealing pump, these powder materials can be quickly transferred from one place to another to meet the production or processing needs.

2. System supporting use

The Low-pressure pneumatic ash conveying material sealing pump can also be used as an integrated part of a large pneumatic conveying system or a powder processing system. According to customers' specific needs and scenarios, the Low-pressure pneumatic ash conveying material sealing pump can be customized and optimized to achieve a more efficient and reliable powder conveying solution.

3. Raw material transportation in industrial production

In electricity industry such as commodity industry, Low-pressure pneumatic ash conveying material sealing pumps are often used as supporting equipment. It can cooperate with other production equipment to realize the automatic and continuous transportation of powder materials. This improves the production efficiency, reduces the labor cost, and helps to realize the automation and intelligence of the production process.

4. Long-distance and complex terrain transportation

The Low-pressure pneumatic ash conveying material sealing pump has the characteristics of Convenient and flexible layout, so it is especially suitable for conveying powder materials in long distance or complex terrain. Whether it is a mountain, a hill or a narrow space in a city, Low-pressure pneumatic ash conveying material sealing pumps can easily cope with all kinds of transportation needs.

5. Waste disposal

Low-pressure pneumatic ash conveying material sealing pumps are also widely used in the field of waste treatment. For example, it can transport fly ash and other wastes to designated disposal sites, or be used in recycling ways such as the production of environmentally friendly bricks. This not only helps to reduce the accumulation and pollution of waste, but also realizes the reuse of resources.

Low-pressure pneumatic ash conveying material sealing pump

6、hyde powder company service

hyde has perfect and reasonable after-sales service, which can solve customers' problems in a short time and reduce customers' losses. hyde powder can provide strong protection for customers in the later stage.。

hyde

Low-pressure pneumatic ash conveying material sealing pumpIt is a new type of powder pneumatic conveying equipment, belonging to the category of low-pressure dilute phase conveying.，Widely used in Dust control, Raw material transportation, Conveying of powdery materials, System supporting use and Dust control。
